0041 hdisk7 00000 000014 Online
00001 000015 Online
0042 hdisk8 00000 000016 Online
00001 000017 Online
0043 hdisk9 00000 000018 Online
00001 000019 Online
KAPL01001-I The HDLM command completed normally. Operation
name = view, completion time = yyyy/mm/dd hh:mm:ss
#
To display LU information (by adding items to be displayed)
-lu -item
The items specified with the -item option are displayed among with those
displayed by the -lu option.
When the value of the -item parameter is omitted or all is specified, all
the items, except for DPC, Physical-LDEV, Virtual-LDEV, Physical-
Product, Physical-SerialNumber, Physical-iLU, Physical-ChaPort,
Org-Product, Org-SerialNumber, and Org-iLU, that can be displayed are
displayed.
The table below lists the correspondence between the display items that
can be added by using the -item parameter and the parameter values
that can be specified after the -item parameter.
Table 6-16 Items That Can Be Added by Using the -lu -item Parameter
and Sub-parameters
Item that can be added Subsequent parameter
SLPR slpr
PathName pn
ChaPort cp
CLPR clpr
Type type
IO-Count ic
IO-Errors ie
DNum dnu
IEP iep
VG vg
DPC dpc
Physical-LDEV phys
Virtual-LDEV virt
Physical-Product vid
Physical-SerialNumber vid
Command Reference
6-59
Hitachi Dynamic Link Manager (for AIX) User Guide
