Item that can be added Subsequent parameter
Physical-iLU vid
Physical-ChaPort vid
Org-Product ha
Org-SerialNumber ha
Org-iLU ha
HaStat hastat
All items are displayed
all
For details on the contents of each displayed item, see Table 6-18
Displayed LU Information on page 6-64.
The sub-parameters are:
-pstv|-vstv
If the -pstv parameter is specified, information about the physical
storage system is displayed. If the -vstv parameter is specified,
information about the storage system recognized by the operating
system is displayed. If neither parameter is specified, information is
displayed according to the value specified in the -pstv parameter of
set operations.
For information about the items that are displayed differently
depending on the specified -pstv and -vstv parameters, see
Table
6-10 Display items for which the display results of the view operation
differ depending on the -pstv parameter specification on page 6-32 in
Parameters on page 6-18.
-hdev host-device-name|-pathid AutoPATH_ID
Filters the information only for the paths accessing the specified host
device, if the -hdev parameter is specified.
Specify hdisk name for host-device-name.
If the -pathid parameter is specified, only information about the LU
connected to the path with the specified AutoPATH_ID is displayed.
-t
Omits the title for each information item.
Example 1
The following example shows how to add SLPR, PathName, ChaPort,
CLPR, Type, IO-Count, IO-Errors, DNum, IEP, and VG to the displayed
items for LU information.
