Example 2
When using Hitachi AMS2000 series, Hitachi SMS series, or HUS100 series
and displaying LU information with DPC added to the display items:
# /usr/DynamicLinkManager/bin/dlnkmgr view -lu -item dpc
Product : HUS100
SerialNumber : 9203008
LUs : 3
Dynamic I/O Path Control : on*
iLU HDevName DPC PathID Status
000006 hdisk0 on 000000 Online
000003 Online
000007 hdisk1 off 000001 Online
000004 Online
000008 hdisk2 on 000002 Online
000005 Online
