Hitachi Dynamic Link Manager Software Users Guide for AIX

#
To display a summary of LU information
-lu -c
When the -c parameter is specified with the -lu parameter, a summary
of LU configuration information is displayed on one line. The total number
of paths recognized by HDLM and the number of online paths are
displayed for each LU.
You cannot specify the -c parameter together with the -hdev or -pathid
parameter.
For details on the contents of each display item, see
Table 6-18 Displayed
LU Information on page 6-64.
The sub-parameters are as follows:
-pstv|-vstv
If the -pstv parameter is specified, information about the physical
storage system is displayed. If the -vstv parameter is specified,
information about the storage system recognized by the operating
system is displayed. If neither parameter is specified, information is
displayed according to the value specified in the -pstv parameter of
set operations.
For information about the items that are displayed differently
depending on the specified -pstv and -vstv parameters, see
Table
6-10 Display items for which the display results of the view operation
differ depending on the -pstv parameter specification on page 6-32 in
Parameters on page 6-18.
-t
Does not display the title for each information item.
Example
The following example shows how to display a summary of the LU
information (without selecting items to be displayed):
# /usr/DynamicLinkManager/bin/dlnkmgr view -lu -c
Product S/N LUs iLU HDevName Paths OnlinePaths
USP 0014010 10 003A hdisk0 2 2
003B hdisk1 2 2
003C hdisk2 2 2
003D hdisk3 2 2
003E hdisk4 2 2
003F hdisk5 2 2
0040 hdisk6 2 2
0041 hdisk7 2 2
0042 hdisk8 2 2
0043 hdisk9 2 2
KAPL01001-I The HDLM command completed normally. Operation
name = view, completion time = yyyy/mm/dd hh:mm:ss
#
