Displayed item
Description
No summary
displayed
Summary
displayed
This number combined with the storage system
name (shown in DskName) identifies the LU that is
accessed by a path.
• For the Lightning 9900V series, Hitachi NSC55,
Hitachi Universal Storage Platform 100, Hitachi
Universal Storage Platform 600, Hitachi
Universal Storage Platform 1100, or HUS VM,
indicated by a hexadecimal number. The first
two characters of iLU are the CU number, and
the last two characters are the internal LU
number within the CU.
• For SVS, indicated by a hexadecimal number.
The first three characters of iLU are the CU
number, and the last two characters are the
internal LU number within the CU. The first
character of the CU number is the value 0.
• For XP20000/XP24000, P9500, or XP7, indicated
by a hexadecimal number. The first two
characters of iLU are 00, the middle two
numbers are the CU number, and the last two
characters are the internal LU number within
the CU.
• For the Thunder 9500V series, Hitachi
AMS2000/AMS/WMS/SMS series, or HUS100
series, indicated by a decimal number. The
entire value of iLU is the internal LU number
within the storage system. You can identify an
actual LU by referencing iLU from the storage
system management program.
• For Universal Storage Platform V/VM series,
Virtual Storage Platform series, or VSP G1000
indicated by a hexadecimal number. The first
two characters of iLU are the number of the
logical DKC (Disk Controller), the middle two
numbers are the CU number, and the last two
characters are the internal LU number within
the CU.
SLPR
#1
SLPR
#2
The number of the SLPR to which an LU belongs,
indicated by a number from 0 to 31. A hyphen (-) is
displayed if the storage logical partition functionality
for the storage system for the target LU is not
supported.
HDevName
#1
-
Host device name.
Hdisk name is displayed.
DPC -
The setting information about the dynamic I/O path
control function is displayed for each LU.
on: The dynamic I/O path control function is
enabled.
Command Reference
6-65
Hitachi Dynamic Link Manager (for AIX) User Guide
