Displayed item
Description
No summary
displayed
Summary
displayed
off: The dynamic I/O path control function is
disabled.
-: The dynamic I/O path control function is not
supported.
OSPathID
-
OS management path ID.
PathID -
AutoPATH_ID indicated by a decimal number.
AutoPATH_ID is assigned when the host is restarted
or when a path configuration is changed. When a
new LU was added and the host has not been
restarted, AutoPATH_ID is assigned to each path of
the LU when you execute the cfgmgr command.
PathName
#1
-
The path name, which indicates a path. When you
modify the system configuration or replace a
hardware item, you should check the path names to
identify the path that will be affected by the change.
Path name consists of the following four elements,
separated by periods:
• HBA adapter number or adapter type (character
string)
• Bus number or adapter number (character
string)
• Target ID (hexadecimal number)
• Host LU number (hexadecimal number)
For details about each element of the path name
and its representation in AIX, see
Table 6-14
Elements of a Path Name on page 6-55
ChaPort
#1
-
Port number of the CHA, which identifies the CHA
port that is mounted on the storage system.
You can identify an actual CHA port by referencing
this number from the storage system management
program.
CLPR
#1
-
The number of the CLPR to which the CHA port
belongs, indicated by a decimal number from 0 to
31. Note that a hyphen (-) is displayed if the
following items are subject to display:
• CHA ports in the storage system that do not
support cache logical partition functionality
• Paths connected to the Snapshot image of the
Copy-on-write Snapshot of the Hitachi
AMS2000/AMS/WMS/SMS series
Status
-
Status of the path
• Online: Online
• Offline(C): Offline status caused by a
command operation
• Offline(E): Offline due to an error
