Displayed item
Description
No summary
displayed
Summary
displayed
• Online(E): Failure has occurred (If none of the
paths accessing one LU have an Online status,
one of those paths is changed to the Online(E)
status.)
• Online(S): I/O operations to the primary
volume (P-VOL) in an HAM environment are
suppressed.
• Online(D): The paths to the primary volume
(P-VOL) in an HAM environment can be
recovered automatically.
Paths that are Offline(E) or Online(E) require
corrective action. The appropriate action can be
determined by referring to
What To Do for a Path
Error on page 5-3
Type
#1
-
Attribute of the path
• Own: Owner path
• Non: Non-owner path
When connected to the Lightning 9900V series,
Hitachi USP series, Universal Storage Platform V/VM
series, Virtual Storage Platform series, VSP G1000
series, Hitachi AMS2000 series
#3
, Hitachi SMS
series
#3
, HUS100 series
#3
, or HUS VM, all paths are
owner paths.
IO-Count
#1
-
Total I/O count for a path. The maximum value that
can be displayed is 2
32
- 1 (4294967295). If the
total I/O count reaches the maximum value, it is
reset, and the count is re-started from 0.
To reset the IO-Count value to 0, execute the
dlnkmgr command's clear operation. Executing the
clear operation also resets the number of I/O
errors (IO-Errors) to 0. For details about the clear
operation, see
clear (Returns the Path Statistics to
the Initial Value) on page 6-3.
IO-Errors
#1
-
Total I/O error count for a path. The maximum value
that can be displayed is 2
32
- 1 (4294967295). If the
total I/O error count reaches the maximum value, it
is reset, and the count is re-started from 0.
To reset the IO-Errors value to 0, execute the
dlnkmgr command's clear operation. Executing the
clear operation also clears the number of I/O
operations (IO-Count) to 0.
For details about the clear operation, see
clear
(Returns the Path Statistics to the Initial Value) on
page 6-3.
DNum
#1
-
Dev number, indicated by a decimal number.
This item pertains to a logical volume number.
