Displayed item
Description
No summary
displayed
Summary
displayed
• For Hitachi Virtual Storage Platform, indicated
by a hexadecimal number. The first two
characters of iLU are the number of the logical
DKC (Disk Controller), the middle two numbers
are the CU number, and the last two characters
are the internal LU number within the CU.
When a virtual ID is not used, a hyphen (-) is
displayed.
Physical-
ChaPort
-
When a path is migrated using a virtual ID, displays
port number of the CHA that is connected by the
migration-destination path.
When a virtual ID is not used, a hyphen (-) is
displayed.
-
Paths
Total number of the paths recognized by HDLM for
the LU to be displayed.
- OnlinePaths
Number of available paths in the displayed paths,
indicated by a decimal number. When the value of
Paths equals the value of OnlinePaths, all paths
are online. If the value of OnlinePaths is less than
that of Paths, some paths are offline. In this case,
you should check the offline paths and take
appropriate action for any paths that have an error
status.
Org-Product
-
For HAM environments, the model ID of the storage
system on the secondary volume (S-VOL) is
displayed.
If an HAM environment is not used, a hyphen (-) is
displayed.
Org-
SerialNumber
-
For HAM environments, the serial number of the
storage system on the secondary volume (S-VOL) is
displayed.
If an HAM environment is not used, a hyphen (-) is
displayed.
Org-iLU
-
For HAM environments, an LU number in the storage
system on the secondary volume (S-VOL) is
displayed.
• For HUS VM, indicated by a hexadecimal
number. The first two characters of iLU are the
CU number, and the last two characters are the
internal LU number within the CU.
• For Hitachi Virtual Storage Platform, indicated
by a hexadecimal number. The first two
characters of iLU are the number of the logical
DKC (Disk Controller), the middle two numbers
are the CU number, and the last two characters
are the internal LU number within the CU.
