Displayed item
Description
No summary
displayed
Summary
displayed
If an HAM environment is not used, a hyphen (-) is
displayed.
Legend:
-: Not displayed
#1
This information is displayed when one of the following conditions exist:
- The user selected the item to be displayed by using the -lu -item
parameter.
- all was specified.
- No value was specified for the parameter.
#2
This information is displayed when one of the following conditions exist:
- The user selected the item to be displayed by using the -lu -c -item
parameter.
- all was specified.
- No value was specified for the parameter.
#3
This storage system applies when the dynamic I/O path control function is
disabled.
To Display HBA Port Information
-hba
Use this parameter to display information about the paths to each HBA
port. HDLM displays the unique HBA port ID assigned to each HBA port.
This HBA port ID can also be used in Offline and Online operations. The
following table lists and describes the displayed items.
Table 6-19 Items Displayed as HBA Port Information
Item Description
HbaID
HBA port ID
Port.Bus
Port (HBA adapter number in character string) and Bus (bus
number in character string), or adapter type and adapter
number, separated by a period
HBAPortWWN
A 16-digit hexadecimal number indicating the WWN information
for an HBA connected to the storage system.
This item is displayed only if -portwwn is specified together with
-hba.
