entering y instructs the DLMgetras utility to overwrite the existing files;
entering n (or anything other than y) instructs the utility to terminate
without executing.
In the latter case, you can either rename the existing directory before re-
executing the utility, or you can execute the utility with a different
directory name specified.
• If you create an archive for the system crash dump collected by the
DLMgetras utility, execute the following:
# cd directory-to-which-collected-information-is-output
# tar cvfh archive-file-name ./var
List of Collected Error Information
The following illustrates the error information collected by executing the
DLMgetras utility, which is explained separately in each output file.
• Name-of-the-directory-containing-a-system-crash-dump-file/name-of-
the-system-crash-dump-file
This file contains a symbolic link to the system crash dump file.
The DLMgetras utility executes the sysdumpdev -l command and sets all
files in the directories that are output to the copy directory value.
•
hbsa.tar.Z
This file contains compressed error information of the Hitachi Command
Suite products other than HDLM.
This file is output only when using the Hitachi Command Suite products
that is the target for collecting error information.
•
getras.tar.Z
This file contains HDLM information and system information.
When you execute the DLMgetras utility, specifying the file that defines
information to be collected, the getras.tar.Z file contains the
information stored in the file that defines information to be collected.
The table below lists and describes the detailed information stored in the
getras.tar.Z file.
This table shows the information collected with or without specifying the
file for defining the information to be collected.
Table 7-2 Information Stored in the getras.tar.Z File
Output directory
#1
Files Explanation
Directly under the
directory to which
collected information is
output
getras.log
DLMgetras utility log file
var/
DynamicLinkManager/log
dlmmgr[1-16].log
HDLM Manager log (including the
driver log)
