Output directory
#1
Files Explanation
dlmwebagent[1-16].
log
Hitachi Command Suite Common
Agent Component log files
dlminquiry[1-2].lo
g
dlminquiry[1-2].tx
t
Inquiry log
dlmguiinst.log
Installation linkage script log
used when linking with Hitachi
Command Suite products other
than HDLM
hdlmtr[1-64].log
Trace file
dlmconfig[1-2].log
dlmconfig[1-2].txt
HDLM configuration log
dlmutil[1-2].log
HDLM utility's log file
installhdlm.log
Unattended installation execution
log
var/
DynamicLinkManager/log
/mmap
hdlmtr.mm
Trace management file
dlmutil.mm
HDLM utility's log trace
management file
opt/hitachi/HNTRLib2/
mmap
hntr2mmap.mm
Memory mapped file (HNTRLib2)
opt/hitachi/
HNTRLib2/etc
D002PPName.log
Log file related to hntr2regist
(HNTRLib2)
opt/hitachi/HNTRLib2/
spool/setuplog
SETUP_D002.log
Log file related to D002setup
(HNTRLib2)
UPDATE_D002.log
Log file related to D002setup
(HNTRLib2)
integrated-trace-file-
output-directory-
specified-in-the-Hitachi-
Network-Objectplaza-
Trace-Library-utility
(Default: var/opt/
hitachi/HNTRLib2/
spool)
integrated-trace-file-
prefix-specified-in-
the-Hitachi-Network-
Objectplaza-Trace-
Library-
utility2[1-64].log
#2
(default prefix: hntr)
Integrated trace file (HNTRLib2)
opt/hitachi/HNTRLib/
mmap
hntrmmap.mm
Memory mapped file (HNTRLib)
output
integrated-trace-file-
output-directory-
specified-in-the-Hitachi-
Network-Objectplaza-
Trace-Library-utility
(Default: opt/hitachi/
HNTRLib/spool)
hntr[1-16].log
Integrated trace file (HNTRLib)
output
Utility Reference
