Output directory
#1
Files Explanation
usr/
DynamicLinkManager/
config
dlmmgr.xml
dlmmgr setting file
dlmwebagent.proper
ties
Hitachi Command Suite Common
Agent Component settings file
dlmmgr_DPC.xml
DPC option setting file
usr/lpp/bosinst cdfs.optional.list
System backup definition file
etc filesystems
Mount information of the file
system
inittab
inittab file
syslog.conf
File for defining the directory for
the output destination of syslog
error-log-file error-log-file Error log file obtained
by /usr/lib/errdemon -1
syslog-output-directory-
name
syslog-name syslog files and backup files
defined in /etc/syslog.conf
getrasinfo
(Not applicable) Directory in which command
execution results are stored
.bash_history
Default history file in the
Bourne Again shell (bash)
.history
Default history file in the C shell
(csh)
.sh_history
Default history file in the Korn
shell (ksh)
alog.txt
System diagnosis message
bootinfo-r.txt
Physical memory size
bootinfo.txt
Information about the operation
mode of the kernel (32/64 bit)
and multi-CPU support
bootlist-v.txt
List of boot devices
Config_Rules.txt
Information of Object Database
Manager
crontab.txt
crontab information
CuAt.txt
Information of Object Database
Manager
CuDv.txt
Information of Object Database
Manager
CuDvDr.txt
Information of Object Database
Manager
CuPath.txt
Information of Object Database
Manager
