Output directory
#1
Files Explanation
CuPathAt.txt
Information of Object Database
Manager
CuVPD.txt
Information of Object Database
Manager
disk.txt
List of disks in the /dev directory
dlmgetomtrace.dmp
HDLM function trace
dlmls-la.txt
HDLM directory information file
dlmmgr-cha.txt
CHA port information
dlmmgr-drv.txt
hdisk information
dlmmgr-hba.txt
HBA port information
dlmmgr-lu.txt
HDLM LU information
dlmmgr-lu-all.txt
HDLM LU information (including
the number of times an
intermittent error occurred)
dlmmgr-path.txt
HDLM path information
dlmmgr-path-
iem.txt
HDLM path information (including
the number of times an
intermittent error occurred)
dlmmgr-sys.txt
HDLM system settings
dlmodmset.txt
HDLM execution environment
ODM settings
dlmpr-k.txt
Persistent reservation key
information
emgr.txt
emgr command
env.txt
Environment variable file
errpt-a.txt
Error log edit file
errpt-t.txt
Error log entries output file
genkex.txt
Information of loaded drivers
hacmp.txt
Information on the PowerHA
configuration
histfile_xxxxx File specified in the HISTFILE
environment variable
iotool.txt
Driver information
lscfg.txt
Firmware version of HBA etc
lsdev-C.txt
Kernel parameter value
lsdev-proc.txt
CPU information
lsfs.txt
File system information
