Output directory
#1
Files Explanation
lslpp.txt
List of installed packages
lspath.txt
MPIO path information
lsps-a.txt
Swap area, usage of swap
lspv.txt
Physical volume information
lsvg.txt
Information of volume groups
Maintenance-
Level.txt
Maintenance level of information,
displayed when the instfix -i
command was executed
mount.txt
Mount information
oslevel.txt
OS level information
pagesize.txt
Memory page size
PdAt.txt
Information of Object Database
Manager
PdAtXtd.txt
Information of Object Database
Manager
PdPathAt.txt
Information of Object Database
Manager
PdDv.txt
Information of Object Database
Manager
ps-ef.txt
Information on the executing
process
ulimit-a.txt
Limits on system resources (data
segments, stack segments, file
descriptors) that are available to
processes
uname-a.txt
Information on the AIX version
viosinfo.txt
Execution result of the VIOS
command
whatlist.txt
Information output by the what
command
etc/multibos/logs op.alog
Multibos log file
etc/VRTSvcs/conf/
config
main.cf
VCS configuration definition file
opt/VRTSvcs/bin/
triggers
preonline
VCS trigger file
var/VRTSvcs/log
/var/VRTSvcs/all-
files-under-log
VCS log file
hacmp.out-output-
directory
hacmp.out
PowerHA execution log
/etc/vsd/ oemdisktypes.lst
VSD settings file
7-12
