# /usr/DynamicLinkManager/bin/dlmchpdattr -a
"reserve_policy=no_reserve queue_depth=4"
KAPL10579-I The HDLM default values will be changed. Is this OK?
[y/n]:y
KAPL10571-I The dlmchpdattr utility completed successfully.
In the following example, the utility displays the current default hdisk
reservation policy:
# /usr/DynamicLinkManager/bin/dlmchpdattr -o
uniquetype = disk/fcp/Hitachi
reserve_policy : no_reserve
KAPL10571-I The dlmchpdattr utility completed successfully.
In the following example, the utility displays Help:
Usage : dlmchpdattr {-a Attribute=Value [Attribute=Value ...]
[-u { HTC | XP }] [-A] [-s] /usr/
DynamicLinkManager/bin/dlmpr -k hdisk1 hdisk2 hdisk3 hdisk4
hdisk5 h| -o | -h}
Attributes
reserve_policy={ PR_exclusive | PR_shared | no_reserve }
max_transfer=Numeric
queue_depth=Numeric
rw_timeout=Numeric
dlmgetrasinst Utility for Collecting HDLM Installation Error
Information
This utility collects information that is needed to analyze errors that have
occurred for some reason during installation of HDLM. The collected
information is archived in a file and saved to the directory that you specified.
The following files are output:
•
getrasinst.tar.Z
This file contains compressed system information.
For details about the information that is stored in the system crash dump file
and getrasinst.tar.Z, see
List of Collected Error Information on page
7-17.
Format
DVD-ROM-drive-directory/HDLM_AIX/hdlmtool/dlmgetrasinst {directory-
to-which-collected-information-is-output | -h}
Parameters
directory-to-which-collected-information-is-output
Specify the output directory for the information that is to be collected by
the dlmgetrasinst utility for collecting HDLM installation error
information. The collected information is compiled into two files shown in
Function and output in the specified directory.
-h
