Displays the format of the dlmgetrasinst utility.
Note
• We recommend that you execute the dlmgetrasinst utility on the HDLM
installation DVD-ROM. If you use the utility by copying it to another
location from the DVD-ROM, also copy the UtilAudLog file to the same
directory to which you copy the dlmgetrasinst file.
• Because dlmgetrasinst first stores error information in the specified
output directory before compressing, ensure that information collection
areas allocated are of adequate size.
• If the specified directory to which collected information is output already
exists, an overwrite confirmation message is displayed. Responding by
entering y instructs the dlmgetrasinst utility to overwrite the existing
files; entering n (or anything other than y) instructs the utility to
terminate without executing.
In the latter case, you can either rename the existing directory before re-
executing the utility, or you can execute the utility with a different
directory name specified.
List of Collected Error Information
The following table lists and describes the information collected by the
dlmgetrasinst utility.
Table 7-4 Information Stored in the getrasinst.tar.Z File
Output directory
#
Files Explanation
Directly under the
directory to which collected
information is output
getrasinst.log
dlmgetrasinst utility log file
etc filesystems
Mount information of the file
system
inittab
inittab file
syslog.conf
File for defining the directory for
the output destination of syslog
log HBaseAgent_install.lo
g
Hitachi Command Suite Common
Agent Component installation log
files
var/tmp D002PPName.log
Log file related to hntr2regist
SETUP_D002.log
Log file related to D002setup
UPDATE_D002.log
Log file related to D002setup
var/adm/ras nimadm.log
Log file related to nimadm
emgr.log
Log file for the emgr command
var/adm/ras/alt_mig
nimadm-log-file-name Log file related to nimadm
Utility Reference
7-17
