Output directory
#
Files Explanation
syslog-output-directory-
name
syslog-name syslog files and backup files
defined in /etc/syslog.conf
getrasinfo
(Not applicable) Directory in which command
execution results are stored
.bash_history
Default history file in the Bourne
Again shell (bash)
.history
Default history file in the C
shell (csh)
.sh_history
Default history file in the Korn
shell (ksh)
bootlist-v.txt
List of boot devices
Config_Rules.txt
Information of Object Database
Manager
crontab.txt
crontab information
CuAt.txt
Information of Object Database
Manager
CuDv.txt
Information of Object Database
Manager
CuDvDr.txt
Information of Object Database
Manager
CuPath.txt
Information of Object Database
Manager
CuPathAt.txt
Information of Object Database
Manager
CuVPD.txt
Information of Object Database
Manager
disk.txt
List of disks in the /dev directory
dlmls-la.txt
HDLM directory information file
env.txt
Environment variable file
errpt-a.txt
Error log edit file
genkex.txt
Information of loaded drivers
histfile_XXXXX
File specified in the HISTFILE
environment variable
lscfg.txt
Firmware version of HBA etc
lsdev-C.txt
Kernel parameter value
lsdev-proc.txt
CPU information
lsfs.txt
File system information
lslpp.txt
List of installed packages
lspath.txt
MPIO path information
