Output directory
#
Files Explanation
lsps-a.txt
Swap area, usage of swap
lspv.txt
Physical volume information
lsvg.txt
Information of volume groups
Maintenance-Level.txt
Maintenance level of information,
displayed when the instfix -i
command was executed
mount.txt
Mount information
oslevel.txt
OS level information
pagesize.txt
Memory page size
PdAt.txt
Information of Object Database
Manager
PdAtXtd.txt
Information of Object Database
Manager
PdPathAt.txt
Information of Object Database
Manager
PdDv.txt
Information of Object Database
Manager
ps-ef.txt
Information on the executing
process
ulimit-a.txt
Limits on system resources (data
segments, stack segments, file
descriptors) that are available to
processes
uname-a.txt
Information on the AIX version
rootvginfo.txt
rootvg information
emgr.txt
The emgr command
viosinfo.txt
The execution results of the VIOS
command
#
An output directory is created in the specified directory when you open
the getrasinst.tar.Z file
dlminstcomp Utility for HDLM Component Installation
This utility complements HDLM installation.
Execute this utility when both of the following conditions are satisfied:
• Linkage with Global Link Manager is used
•
When HDLM is installed, the KAPL09241-W message is output
#
#
Utility Reference
7-19
Hitachi Dynamic Link Manager (for AIX) User Guide
