Execute this utility after installing the JDK.
For details about the JDK version to be installed, see the JDK required for
linkage with Global Link Manager section in Host and OS Support for
HDLM on page 3-3.
Format
/usr/DynamicLinkManager/bin/dlminstcomp [-h]
Parameter
-h
Displays the format of the dlminstcomp utility.
dlmmigsts Utility for Assisting HDLM Migration
This utility saves HDLM program information and the HDLM execution
environment ODM settings, making it possible to inherit settings information
when migrating from HDLM version 5.8.1 or earlier to version 5.9. Execute
this utility from the HDLM version 5.9 installation DVD-ROM.
Format
DVD-ROM-drive-directory
/HDLM_AIX/hdlmtool/dlmmigsts
{{{-b | -r} -odm odm-environment-settings-file-name -set set-
environment-settings-file-name [-s]}
| -h
}
Parameters
-b
Saves the settings files by using the names specified in the -odm and -set
parameters.
Notes on specifying the -b parameter
• Do not save odm-environment-settings-file and set-environment-
settings-file to an HDLM-related directory. If you do so, the saved
file will be deleted during HDLM removal.
The followings are HDLM-related directories:
/usr/DynamicLinkManager
/var/DynamicLinkManager
/var/DLM
/opt/hitachi
