Specify the name of the physical volume on which the persistent
reservation you want to cancel is registered. You can specify only one
name for hdisk-name.
-h
Displays the format of the dlmrmprshkey utility.
Notes
• Verify that the specified physical volume is not used. If it is used, the
dlmrmprshkey utility fails with an error.
• Verify that no error has occurred on the path connected to the specified
physical volume. If an error has occurred, the persistent reservation
(shared-host methodology) cannot be canceled.
Examples
In the following example, the utility cancels persistent reservation (shared-
host methodology) on the specified volume:
# /usr/DynamicLinkManager/bin/dlmrmprshkey -l hdisk8
KAPL13163-I The dlmrmprshkey utility will now be executed. Is
this OK? [y/n]:y
KAPL13157-I The dlmrmprshkey utility completed successfully.
In the following example, the utility displays Help:
# /usr/DynamicLinkManager/bin/dlmrmprshkey -h
Usage : dlmrmprshkey {-l HDLM_device_name | -h}
installhdlm Utility for Installing HDLM
This utility is used to execute an unattended installation when a new
installation, upgrade installation, or re-installation of HDLM is being
performed. You can perform an unattended installation even when you are
installing HDLM in a boot disk environment. Before you perform an
unattended installation, you must define the information that is required
during the installation in the installation information settings file.
For details about how to perform an unattended installation, see
Performing
an Unattended Installation of HDLM on page 3-69.
Format
/directory-in-which-the-DVD-ROM-is-mounted-or-copied/HDLM_AIX/
hdlmtool/instutil/installhdlm { -f installation-information-settings-
file-name | -h}
Parameters
-f
installation-information-settings-file-name
Defines the information needed for installing HDLM.
7-32
