For details about the installation-information settings file, see Items To Be
Defined in an installation-information Settings File on page 7-33.
-h
Displays the format of the installhdlm utility.
Items To Be Defined in an installation-information Settings File
The following describes the information defined in the installation information
settings file.
[INSTALLATION_SETTINGS] section
This section defines information that is used when the installhdlm utility is
executed. Specify this section name at the beginning of the installation
information settings file (although an empty paragraph or comment line can
be inserted above this section name).
The following table lists and describes the keys defined in the
[INSTALLATION_SETTINGS] section.
Table 7-5 Keys in the [INSTALLATION_SETTINGS] Section
Key name
#1
Description
#2
Necessity of
definition
Maxim
um
number
of
charact
ers
New
installa
tion
Upgrade
installatio
n or re-
installatio
n
installfile_locati
on
Specify the absolute path name
of the directory that contains the
DLManager.mpio.bff file from
either the directory in which the
DVD-ROM was mounted or the
directory in which the DVD-ROM
was copied.
The default is /dev/cd0.
Optional Optional 60
logdir
Specify the absolute path name
of the directory in which the file
that contains log information is
output.
The default is /var/tmp. For
details about the log file, see
Log
file on page 7-43.
Optional Optional 60
licensekeyfile
#3
Specify an absolute path to a
license key file stored in the
host. The file specified here is
not deleted after an unattended
installation is performed.
Optional
#4
Optional
#4
60
