Key name
#1
Description
#2
Necessity of
definition
Maxim
um
number
of
charact
ers
New
installa
tion
Upgrade
installatio
n or re-
installatio
n
The default is /var/tmp/
hdlm_license.
If you perform an upgrade
installation or re-installation
without updating the license,
delete the licensekeyfile key
and value.
licensekey
#3
Specify the absolute path name
of the file that records the
license key stored on the host.
The file specified here is not
deleted after an unattended
installation is performed.
The default is /var/DLM/
dlm.lic_key.
If you perform an upgrade
installation or re-installation
without updating the license,
delete the licensekey key and
value.
Optional
#4
Optional
#4
60
driver_config
Specify one of the following
values to indicate whether to
configure the HDLM driver:
y: Configure the HDLM driver
(default).
n: Do not configure the HDLM
driver.
In a boot disk environment, the
HDLM driver is not configured,
regardless of the value specified
here.
Optional Optional 1
restart
Specify whether to restart the
host after installation. Specify
either of the following values:
y: Restart.
n: Do not restart (default).
Optional Optional 1
Legend:
Optional: If a key and its setting are not specified, the default value will
be used.
