However, for an upgrade installation or re-installation, the previous
license information will be inherited for the licensekeyfile and
licensekey keys.
#1
Enter one key and one setting per line.
#2
If the value is not of an allowable type, an error will occur.
#3
You need to delete the licensekeyfile key if you specify the
licensekey key. However, you do not need to delete the licensekey key
if you specify the licensekeyfile key.
If no value is specified for either of these keys, the files below are read in
the order listed:
a. License key file (/var/tmp/hdlm_license)
b. File containing the license key (/var/DLM/dlm.lic_key)
If none of these files exist when you attempt to perform a new
installation, unattended installation ends with an error.
#4
When you perform a new installation of HDLM, or when you perform an
upgrade installation while the license is expired, prepare the license key
or the license key file.
[DISK_DEFAULT_SETTINGS] section
This section defines operation information for the HDLM default settings
modification utility (dlmchpdattr). This section can be omitted. If the section
name is omitted, or the section contains no defined keys, the dlmchpdattr
utility cannot be used to specify settings.
For details about the dlmchpdattr utility, see dlmchpdattr Utility for
Changing HDLM Default Settings on page 7-13.
The following table lists and describes the keys defined in the
[DISK_DEFAULT_SETTINGS] section.
