Table 7-6 Keys in the [DISK_DEFAULT_SETTINGS] Section
Key name
#1
Description
#2
Necessity of
definition
Maxim
um
number
of
charact
ers
New
installa
tion
Upgrade
installatio
n or re-
installatio
n
reserve_policy
Specify the disk reservation
policy.
no_reserve: Reservation
requests are ignored, and no LU
is reserved.
PR_exclusive: Uses persistent
reservations (exclusive-host
methodology) to reserve disks
(default).
PR_shared: Uses persistent
reservations (shared-host
methodology) to reserve disks.
Optional Optional 12
Legend:
Optional: If a key and its setting are not specified, one of the following
values will be used:
¢
For a new installation:
The default value will be used.
¢
For an upgrade installation or re-installation:
The previous setting will be inherited.
#1
Enter one key and one setting per line.
#2
If the value is not of an allowable type, an error will occur.
[ODM_SETTINGS] section
Defines information used when the dlmodmset utility is executed. This section
is optional. If this section name is omitted, or if any of the keys in the section
are not defined, setup by means of the dlmodmset utility will not be executed.
For details about the dlmodmset utility, see dlmodmset Utility for Setting the
HDLM Execution Environment ODM on page 7-22.
The following table lists and describes the keys defined in the
[ODM_SETTINGS] section.
