Key name
#1
Description
#2
Necessity of
definition
Maxim
um
numbe
r of
charac
ters
New
installa
tion
Upgrad
e
installa
tion or
re-
installa
tion
(rr), Least I/Os (lio), or Least
Blocks (lbk) algorithm is used for
load balancing.
You can specify a value from 0 to
999999. The default is 20.
lbex_usetimes_limi
t
Specify the number of times the
same path can be used for
sequential I/O operations when the
extended Round Robin (exrr),
Least I/Os (exlio), or Least Blocks
(exlbk) algorithm is used for
extended load balancing.
You can specify a value from 0 to
999999. The default is 100.
Optional Optional 6
error_log_level
Set the level of error information
that is collected as error logs.
You can set a level from 0 to 4. The
default is 3.
Optional Optional 1
error_log_size
Set the size of the error log files
(dlmmgr[1-16].log) in kilobytes.
You can set a size from 100 to
2000000. The default is 9900.
Optional Optional 7
error_log_number
Set the number of error log files
(dlmmgr[1-16].log).
You can set a value from 2 to 16.
The default is 2.
Optional Optional 2
trace_level
Set the trace output level.
You can set a level from 0 to 4. The
default is 0.
Optional Optional 1
trace_file_size
Set the size of the trace files
(hdlmtr[1-64].log) in kilobytes.
You can set a size from 100 to
16000. The default is 1000.
Optional Optional 5
trace_file_number
Set the number of trace files
(hdlmtr[1-64].log).
You can set a value from 2 to 64.
The default is 4.
Optional Optional 2
