Key name
#1
Description
#2
Necessity of
definition
Maxim
um
numbe
r of
charac
ters
New
installa
tion
Upgrad
e
installa
tion or
re-
installa
tion
path_health_check
Specify one of the following values
to indicate whether to enable or
disable the path health check
function:
on: Enabled (default)
off: Disabled
Optional Optional 3
path_health_check_
interval
Specify the interval in minutes at
which the path health check is
performed.
You can specify a check interval
from 1 to 1440. The default is 30.
Optional Optional 4
auto_failback
Specify one of the following values
to indicate whether to enable or
disable the automatic failback
function for failed paths:
on: Enabled (default)
off: Disabled
Optional Optional 3
auto_failback_inte
rval
Specify the interval in minutes from
the time the previous path status
check finished until the time the
next path status check started.
You can specify a check interval
from 1 to 1440. The default is 60.
Optional Optional 4
intermittent_error
_monitor
#3, #4
Specify one of the following values
to indicate whether to enable or
disable intermittent error
monitoring:
on: Enabled
off: Disabled (default)
Optional Optional 3
intermittent_error
_monitor_interval
#
4
Specify the interval in minutes that
monitoring for intermittent errors is
performed.
You can specify a check interval
from 1 to 1440. The default is 210.
Optional Optional 4
intermittent_error
_monitor_number
#4
Specify the number of times an
error (that is assumed to be an
intermittent error) occurs. You can
specify a value from 1 to 99. The
default is 3.
Optional Optional 2
