Key name
#1
Description
#2
Necessity of
definition
Maxim
um
numbe
r of
charac
ters
New
installa
tion
Upgrad
e
installa
tion or
re-
installa
tion
dynamic_io_path_co
ntrol
Specify whether to enable or
disable the dynamic I/O path
control function by using the values
below. Note that, if this function is
set, the setting for each storage
system or LU is cleared.
on: Enabled
off: Disabled (default)
Optional Optional 3
dynamic_io_path_co
ntrol_interval
For the dynamic I/O path control
function, specify the checking
interval (in minutes) for reviewing
the information about the switching
of controllers performed by the
storage system.
#5
You can set the checking interval
from 1 to 1440. The default is 10.
Optional Optional 4
Legend:
Optional: If a key and its setting are not specified, one of the following
values will be used:
¢
For a new installation
The default value will be used.
¢
For an upgrade installation or re-installation:
The previous setting will be inherited.
Note:
Setting of audit logs is not supported.
#1
Enter one key and one setting per line.
#2
If the value is not of an allowable type, an error will occur.
For details about the functions set by these keys, see set (Sets Up the
Operating Environment) on page 6-18.
#3
You can specify this key only in the following cases:
¢
For a new installation:
Utility Reference
7-41
Hitachi Dynamic Link Manager (for AIX) User Guide
