If a hash mark (#) is placed at the beginning of a line in the
installation information settings file, that line is assumed to be a
comment.
¢
If you do not want to specify a key, enter a hash mark (#) at the
beginning of the line that defines that key.
Log file
A log file (installhdlm.log) is output after an unattended installation of
HDLM.
The following explains the installhdlm.log file.
• installhdlm.log is created in the folder whose path is specified by the
logdir key in the installation-information settings file. Do not share the
log file output directory among the hosts on which unattended installation
is being performed. If no value is specified for logdir key, the log file is
output to the /var/tmp directory.
• If installhdlm.log already exists, log information is added to this log
file. For details about the unused capacity required for the log output
directory, see
Performing an Unattended Installation of HDLM on page
3-69.
Note
• Note that installhdlm.log is not deleted after HDLM is removed.
Therefore, delete the original installhdlm.log manually if it is no longer
required.
• If the installhdlm.log file cannot be output for some reason, such as
there being insufficient capacity on the output disk, a message is output
to this effect immediately before the installhdlm utility ends.
installux.sh Utility for HDLM Common Installer
This utility determines what OS HDLM will be installed on, and installs the
corresponding version of HDLM from the DVD-ROM. This utility can also
perform unattended installations via a parameter specification.
For details about how to use this utility to install HDLM, see
Performing a New
Installation of HDLM on page 3-26, Performing an Upgrade Installation or Re-
installation of HDLM on page 3-38, or Performing an Unattended Installation
of HDLM on page 3-69.
Format
/directory-in-which-the-DVD-ROM-is-mounted-or-copied/installux.sh [ -f
installation-information-settings-file-name | -h]
