Message
ID
Message Text Explanation
(dlnkmgr) to check the
operation name, and then
retry. For details on the
help operation, see help
(Displays the Operation
Format) on page 6-4.
KAPL01005-
W
A parameter is invalid. Operation name =
aa...aa, parameter = bb...bb
Details
aa...aa: Specified
operation name
bb...bb: Specified
parameter
Action
Execute help operation-
name of the HDLM
command (dlnkmgr) to
check the parameter, and
then retry. For details on
the help operation, see
help (Displays the
Operation Format) on page
6-4.
KAPL01006-
W
A necessary parameter is not specified.
Operation name = aa...aa
Details
The specified operation
does not contain the
necessary parameter.
aa...aa: Specified
operation name
Action
Execute help operation-
name of the HDLM
command (dlnkmgr) to
check the parameter.
Specify the correct
parameter, and then retry.
For details on the help
operation, see
help
(Displays the Operation
Format) on page 6-4.
KAPL01007-
W
A duplicate parameter is specified.
Operation name = aa...aa, parameter =
bb...bb
Details
aa...aa: Specified
operation name
bb...bb: Duplicate
parameter
Action
Delete the duplicate
parameter, and then retry.
KAPL01008-
W
A necessary parameter value is not
specified. Operation name = aa...aa,
parameter = bb...bb
Details
