Message
ID
Message Text Explanation
aa...aa: Specified
operation name
bb...bb: Parameter name
Action
Specify the parameter
value, and then retry.
KAPL01009-
W
A parameter value is invalid. Operation
name = aa...aa, parameter = bb...bb,
parameter value = cc...cc, Valid value =
dd...dd
Details
aa...aa: Specified
operation name
bb...bb: Parameter name
cc...cc: Specified
parameter value
dd...dd: Specifiable
parameter value range
Action
Specify a correct value for
the parameter, and then
retry.
KAPL01012-
E
Could not connect the HDLM manager.
Operation name = aa...aa
Details
In the view -sys -sfunc
operation, information
must be collected from the
HDLM manager but the
manager cannot be
accessed.
aa...aa: view
Action
Execute the view operation
of the HDLM command
(dlnkmgr) to check
whether the HDLM
manager has started. Start
the HDLM manager if it has
not started, and then retry
the HDLM command. For
details on the view
operation, see
view
(Displays Information) on
page 6-34.
KAPL01013-
E
An error occurred in internal processing of
the HDLM command. Operation name =
aa...aa details = bb...bb
Details
An error unrelated to a
user operation occurred
during command
processing.
aa...aa: Specified
operation name
8-6
Messages
Hitachi Dynamic Link Manager (for AIX) User Guide
