Message
ID
Message Text Explanation
bb...bb: The name of the
function and processing on
which the error occurred
Action
Execute the DLMgetras
utility for collecting HDLM
error information, and then
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL01014-
W
No authority to execute the HDLM
command. Operation name = aa...aa
Details
You do not have the
administrator permissions
necessary to execute the
HDLM command.
aa...aa: Specified
operation name
Action
Execute the command as a
user with root permissions.
KAPL01015-
W
The target HBA was not found. Operation
name = aa...aa
Details
No path was found with
the port number and path
number, or the adapter
type and adapter number,
specified for the -hba
parameter.
aa...aa: offline or online
Action
Execute the view operation
of the HDLM command
(dlnkmgr view -path) and
check the value displayed
in PathName. Use the two
leftmost digits of PathName
for the relevant HBA port,
and then retry. For details
on the view operation, see
view (Displays
Information) on page 6-34.
KAPL01016-
W
The target CHA port was not found.
Operation name = aa...aa
Details
The path ID of the path
management path
(Path_ID) specified in the
