Message
ID
Message Text Explanation
-pathid option required by
the -cha parameter could
not be found, or the CHA
that has the channel ID
(CHA_ID) specified in the -
chaid parameter could not
be found.
aa...aa: offline or online
Action
¢
If the path ID of the
path management
path was specified in -
pathid
Execute the view
operation of the HDLM
command (dlnkmgr
view -path), and
check the value of the
target CHA port and
the path ID of the path
management path that
passes through that
CHA port. Then,
specify the applicable
path management
path ID, and retry the
operation. For details
about the view
operation, see
view
(Displays Information)
on page 6-34.
¢
If the channel ID
(CHA_ID) was specified
in -chaid
Execute the view
operation of the HDLM
command (dlnkmgr
view -cha), and check
the target CHA port
and the CHA ID of that
CHA port. Then,
specify the applicable
CHA ID, and retry the
operation. For details
about the view
operation, see
view
(Displays Information)
on page 6-34.
KAPL01018-
W
The target device was not found.
Operation name = aa...aa
Details
The specified host device
name could not be found.
aa...aa: view
