Message
ID
Message Text Explanation
Action
Execute the view operation
of the HDLM command
(dlnkmgr view -path) to
check the value displayed
in HDevName. Specify a
host device for the value of
HDevName, and then retry.
For details on the view
operation, see
view
(Displays Information) on
page 6-34.
KAPL01019-
W
The target path was not found. Operation
name = aa...aa
Details
aa...aa: offline, online,
or view
¢
offline/online
operation
The specified path
does not exist.
¢
view operation
The paths have not
been configured
because creation of
the HDLM environment
or configuration
changes to the HDLM
operating environment
have not finished.
Action
¢
offline/online
operation
Use the view
operation of the HDLM
command (dlnkmgr)
to check the settings,
and then retry. For
details on the view
operation, see view
(Displays Information)
on page 6-34.
¢
view operation
Refer to Chapter 3,
Creating an HDLM
Environment on page
3-1. Creating an HDLM
Environment or
Changing the
Configuration of the
HDLM Operating
Environment on page
4-15, and then
Messages
8-9
