Message
ID
Message Text Explanation
Execute help operation of
the HDLM command
(dlnkmgr) to check which
parameters can be
specified at the same time,
and then retry. For details
on the help operation, see
help (Displays the
Operation Format) on page
6-4.
KAPL01036-
E
The Offline path cannot be placed online.
PathID = aa...aa
Details
aa...aa: Path ID (decimal
(base-10) number)
Action
Remove the error in the
path, and then retry.
KAPL01039-
W
During the online operation processing of
the HDLM command, a path that cannot
be placed in the Online status was
detected. PathID = aa...aa Would you like
to continue the processing of the online
operation? [y/n]:
Details
A path that cannot be
placed Online was detected
during multipath online
processing.
To ignore this path and
perform online processing
for the next path, enter y.
To cancel processing, enter
n.
aa...aa: Path ID (decimal
(base-10) number)
Action
If you want to continue
processing of the online
operation of the HDLM
command for other paths,
enter y. If you want to
terminate processing,
enter n. For details on the
online operation, see
online (Places Paths
Online) on page 6-11.
KAPL01040-
W
The entered value is invalid. Re-enter
[y/n]:
Details
A value other than y and n
was entered. Enter y or n.
Action
Enter y or n.
KAPL01041-
E
The entered value is invalid. The
operation stops. Operation name =
aa...aa
Details
Command processing will
be aborted because an
Messages
8-11
