Message
ID
Message Text Explanation
incorrect value was
entered three times in a
row for a request.
aa...aa: clear, offline,
online, or set
Action
Check the correct value,
and then re-execute the
HDLM command.
KAPL01044-
W
A duplicate parameter value is specified.
Operation name = aa...aa, parameter =
bb...bb, parameter value = cc...cc
Details
aa...aa:view
bb...bb: Parameter name
cc...cc: Duplicate
parameter value
Action
Delete the duplicate
parameter value, and then
retry.
KAPL01045-
W
Too many parameter values are specified.
Operation name = aa...aa, parameters =
bb...bb, parameter value = cc...cc
Details
aa...aa: offline, online,
set, or view
bb...bb: Parameter name
cc...cc: Parameter value
Action
Execute help operation-
name of the HDLM
command (dlnkmgr) to
check the parameter value,
and then retry. For details
on the help operation, see
help (Displays the
Operation Format) on page
6-4.
KAPL01048-
W
Help information cannot be found.
Operation name = aa...aa.
Details
The specified operation is
not an operation of the
HDLM command.
aa...aa: Specified
operation name
Action
Use the help operation of
the HDLM command
(dlnkmgr) to check the
operation name. And then
retry. For details on the
help operation, see
help
8-12
