Message
ID
Message Text Explanation
(Displays the Operation
Format) on page 6-4.
KAPL01049-
I
Would you like to execute the operation?
Operation name = aa...aa [y/n]:
Details
The clear/set operation
will be started. To continue
the operation, enter y. To
cancel the operation, enter
n.
aa...aa: clear or set
Action
If you want to execute the
operation, enter y. If you
want to terminate
processing, enter n. For
details on the clear
operation, see
clear
(Returns the Path Statistics
to the Initial Value) on
page 6-3. For details on
the set operation, see set
(Sets Up the Operating
Environment) on page
6-18.
KAPL01050-
I
The currently selected paths will be
changed to the Online status. Is this OK?
[y/n]:
Details
The online operation will
be started. To continue the
online operation, enter y.
To cancel the operation,
enter n.
Action
If you want to execute
online processing, enter
y. If you want to terminate
processing, enter n. For
details on the online
operation, see online
(Places Paths Online) on
page 6-11.
KAPL01051-
I
Because no path has been selected
among the currently displayed paths, the
paths in the Offline(C), Offline(E), and
Online(E) statuses will be changed to the
Online status. Is this OK? [y/n]:
Details
All the paths will be placed
Online because the path
selection parameter is not
specified for the online
operation. To place all the
paths Online, enter y. To
cancel the operation, enter
n.
Action
If you want to execute
online processing, enter
