Message
ID
Message Text Explanation
y. If you want to terminate
processing, enter n. Before
you execute the
processing, be sure to
execute the view operation
of the HDLM command
(dlnkmgr) to check the
path status. For details on
the view operation, see
view (Displays
Information) on page 6-34.
For details on the online
operation, see online
(Places Paths Online) on
page 6-11.
KAPL01052-
I
The currently selected paths will be
changed to the Offline(C) status. Is this
OK? [y/n]:
Details
The offline operation will
be started. To continue the
offline operation, enter
y. To cancel the operation,
enter n.
Action
If you want to execute the
offline processing, enter y.
If you want to terminate
processing, enter n. For
details on the offline
operation, see
offline
(Places Paths Offline) on
page 6-6.
KAPL01053-
I
If you are sure that there would be no
problem when the path is placed in the
Offline(C) status, enter y. Otherwise,
enter n. [y/n]:
Details
The offline operation will
be started. To continue the
offline operation, enter
y. To cancel the operation,
enter n.
Action
If you want to execute
offline processing, enter
y. If you want to terminate
processing, enter n. For
details on the offline
operation, see offline
(Places Paths Offline) on
page 6-6.
KAPL01054-
W
During the offline operation processing of
the HDLM command, a path that cannot
be placed in the Offline(C) status was
detected. PathID = aa...aa Would you like
to continue the processing of the offline
operation? [y/n]:
Details
A path that cannot be set
to Offline(C) was detected
during multipath offline
processing. To ignore this
path and perform offline
8-14
