Message
ID
Message Text Explanation
processing for the next
path, enter y. To cancel
offline processing, enter n.
aa...aa: Path ID (decimal
(base-10) number)
Action
If you want to continue
processing the offline
operation of the HDLM
command for other paths,
enter y. If you want to
terminate processing,
enter n. For details on the
offline operation, see
offline (Places Paths
Offline) on page 6-6.
KAPL01055-
I
All the paths which pass the specified
aa...aa will be changed to the Offline(C)
status. Is this OK? [y/n]:
Details
Multiple paths will be
collectively set to
Offline(C) because the -
hba or -cha parameter was
specified. To collectively
set place multiple paths to
Offline(C), enter y. To
cancel the operation, enter
n.
aa...aa: CHA port, HBA
Action
If you want to execute
offline processing for the
paths that meet the
specified requirements,
enter y. If you want to
terminate processing,
enter n.
KAPL01056-
I
If you are sure that there would be no
problem when all the paths which pass
the specified aa...aa are placed in the
Offline(C) status, enter y. Otherwise,
enter n. [y/n]:
Details
This message re-asks the
user whether they want to
set place all the paths to
Offline(C). To set all the
paths to Offline(C), enter
y. To cancel the operation,
enter n.
aa...aa: CHA port, HBA
Action
If you want to execute
offline processing for the
paths that meet the
specified requirements,
enter y. If you want to
