Message
ID
Message Text Explanation
terminate processing,
enter n.
KAPL01057-
I
All the paths which pass the specified
aa...aa will be changed to the Online
status. Is this OK? [y/n]:
Details
Multiple paths will all be
placed in Online status
because the -hba or -cha
parameter was specified.
To continue the operation,
enter y; to cancel the
operation, enter n.
aa...aa: CHA port, HBA
Action
If you want to execute
online processing for the
paths that meet the
specified requirements,
enter y. If you want to
terminate processing,
enter n.
KAPL01058-
W
The specified parameter value is not
needed. Operation name = aa...aa,
parameter = bb...bb, parameter value =
cc...cc
Details
A parameter value was
specified in a parameter
that does not need a any
parameter value.
aa...aa: Specified
operation name
bb...bb: Parameter name
cc...cc: Parameter value
Action
Execute help operation-
name of the HDLM
command (dlnkmgr) to
check the parameter and
parameter value, and then
retry. For details on the
help operation, see
help
(Displays the Operation
Format) on page 6-4.
KAPL01059-
W
Cannot specify the parameter aa...aa at
the same time if you specify parameter
bb...bb and parameter value cc...cc.
Operation name = dd...dd
Details
A parameter value is
conflicting with the value
of another parameter.
bb...bb: Parameter name
cc...cc: Parameter value
aa...aa: Parameter name
dd...dd: view or set
Action
