Message
ID
Message Text Explanation
Execute help operation-
name of the HDLM
command (dlnkmgr) to
check the parameter and
parameter value, and then
retry. For details on the
help operation, see
help
(Displays the Operation
Format) on page 6-4.
KAPL01060-
I
The user terminated the operation.
Operation name = aa...aa
Details
Command processing will
be aborted because n was
entered for a required
confirmation.
aa...aa: online, offline,
set, or clear
Action
None.
KAPL01061-
I
aa...aa path(s) were successfully placed
bb...bb; cc...cc path(s) were not.
Operation name = dd...dd
Details
This message indicates the
number of the paths
processed in an online/
offline operation.
aa...aa: Number of paths
where the online/offline
operation was successful
(decimal (base-10)
number)
bb...bb: Online,
Online(S), Online(D) or
Offline(C)
cc...cc: Number of paths
where the online/offline
operation was unsuccessful
(decimal (base-10)
number)
dd...dd: online, or
offline
Action
None. For details on the
online operation, see
online (Places Paths
Online) on page 6-11. For
details on the offline
operation, see offline
(Places Paths Offline) on
page 6-6.
KAPL01063-
I
The target path(s) are already aa...aa. Details
Messages
8-17
Hitachi Dynamic Link Manager (for AIX) User Guide
