Message
ID
Message Text Explanation
As a result of a previous
online/offline operation,
the specified path has
already been set to
Online/Online(S)/
Online(D)/Offline(C).
aa...aa: Online,
Online(S), Online(D),
or Offline(C)
Action
Use the view operation of
the HDLM command
(dlnkmgr) to check the
status of the path. For
details on the view
operation, see
view
(Displays Information) on
page 6-34. For details on
the online operation, see
online (Places Paths
Online) on page 6-11. For
details on the offline
operation, see
offline
(Places Paths Offline) on
page 6-6.
For Online(S) or
Online(D) paths:
To change the status of a
path from Online(S) or
Online(D) to Online, re-
execute the HDLM
command using the -
hapath parameter.
KAPL01068-
I
Enter a license key: Details
The license key will now be
renewed. Enter a license
key.
Action
None.
KAPL01069-
W
The entered license key is invalid. Details
The entered license key is
invalid.
Action
Enter a valid license key.
KAPL01070-
E
The entered license key is invalid.
Renewal of the license key will now stop.
Details
The license key renewal
processing will be aborted
because an invalid license
8-18
Messages
