Message
ID
Message Text Explanation
key was entered three
times in a row.
Action
Obtain a valid license key,
and then retry.
KAPL01071-
I
The permanent license was installed. Details
The license was renewed
and is registered as a
permanent license.
Action
None.
KAPL01072-
I
The emergency license was installed. The
license expires on aa...aa.
Details
A license was renewed and
is registered as an
emergency license.
aa...aa: Year (4 digits)/
month (01-12)/day
(01-31)
Action
Install a permanent license
by the expiration day.
KAPL01073-
E
The temporary license expired. Details
The temporary license has
expired. Register a
permanent license.
Action
Register a permanent
license.
KAPL01074-
E
The emergency license expired. Details
The emergency license has
expired. Register a
permanent license.
Action
Register a permanent
license.
KAPL01075-
E
A fatal error occurred in HDLM. The
system environment is invalid.
Details
The license information file
is missing.
Action
Re-install HDLM.
KAPL01076-
I
The permanent license has been installed. Details
You need not install a
license because a
permanent license has
already been installed.
