Message
ID
Message Text Explanation
Action
None.
KAPL01078-
W
The operation terminated because the
path configuration changed during
execution of the HDLM command.
Operation name = aa...aa
Details
aa...aa:offline, online,
view
Action
After the processing to
change the path
configuration has finished,
retry.
KAPL01079-
W
The intermittent error monitoring function
cannot be set up because automatic
failback is disabled.
Details
The intermittent error
monitoring function cannot
be set up because
automatic failbacks are
disabled.
Action
Enable automatic failbacks,
and then re-execute.
KAPL01080-
W
The error monitoring interval and the
number of times that the error is to occur
conflict with the automatic failback
checking interval.
Details
An intermittent error
cannot be detected by
using the values specified
for the following: the
checking interval for
automatic failbacks, the
error-monitoring interval,
and the number of times
the error needs to occur.
Action
Set the intermittent error-
monitoring interval to a
value that is equal to or
greater than (automatic-
failback-checking-interval x
number-of-times-error-is-
to-occur-for-intermittent-
error-monitoring).
KAPL01081-
E
The license key file is invalid. File name =
aa...aa
Details
The format of the license
key file is invalid.
aa...aa: /var/tmp/
hdlm_license
Action
Save the correct license
key file in the designated,
and then re-execute.
/var/tmp/hdlm_license
