Message
ID
Message Text Explanation
KAPL01082-
E
There is no installable license key in the
license key file. File name = aa...aa
Details
There is no useable license
key for HDLM in the license
key file.
aa...aa: /var/tmp/
hdlm_license
Action
Make sure that the license
key file is correct, and then
re-execute.
/var/tmp/hdlm_license
KAPL01083-
I
There is no license key file. File name =
aa...aa
Details
There is no license key file
in the designated
directory:
aa...aa: /var/tmp/
hdlm_license
Action
When the message that
prompts you to enter the
license key is displayed,
enter the license key.
Alternatively, cancel the
HDLM command, save the
correct license key file in
the designated directory,
and then re-execute the
HDLM command.
aa...aa: /var/tmp/
hdlm_license
KAPL01084-
W
An attempt to delete the license key file
has failed. File name = aa...aa
Details
aa...aa: /var/tmp/
hdlm_license
Action
If a license key file exists,
delete it.
aa...aa: /var/tmp/
hdlm_license
KAPL01088-
W
The specified parameter values cannot be
specified at the same time. Operation
name = aa...aa, parameter = bb...bb,
parameter values = cc...cc
Details
aa...aa:view
bb...bb: Parameter name
cc...cc: Parameter values
that cannot be specified at
the same time
Action
Messages
8-21
Hitachi Dynamic Link Manager (for AIX) User Guide
