Message
ID
Message Text Explanation
Execute help operation-
name of the HDLM
command (dlnkmgr) to
check which parameter can
be specified, and then
retry. For details on the
help operation, see
help
(Displays the Operation
Format) on page 6-4.
KAPL01089-
E
One of the following was executed at the
same time as an HDLM command set -lic
operation: another set -lic operation, or
an update of the license for an update
installation.
Action
Check the license by using
the HDLM command's view
-sys -lic operation. If
necessary, re-execute the
HDLM command's set -
lic operation. If the same
error message is output
again, contact your HDLM
vendor or the maintenance
company if there is a
maintenance contract for
HDLM.
Do not perform the
following operations:
¢
Simultaneously
execute the HDLM
command's set -lic
operation with the
view -sys -lic
operation.
¢
Execute the HDLM
command's set -lic
operation while the
license for an upgrade
or re-installation is
being updated.
KAPL01095-
E
An attempt to acquire the HDLM version
information has failed. details = aa...aa
Details
aa...aa: Code showing the
reason for the error
Action
Re-execute the command.
If the same error occurs
again, execute the
DLMgetras utility for
collecting HDLM error
information, acquire the
error information, and then
contact your HDLM vendor
or the company for which
you have a service
contract.
8-22
Messages
Hitachi Dynamic Link Manager (for AIX) User Guide
