Message
ID
Message Text Explanation
KAPL01096-
E
An attempt to acquire the Service Pack
version information has failed. details =
aa...aa
Details
aa...aa: Code showing the
reason for the error
Action
Re-execute the command.
If the same error occurs
again, execute the
DLMgetras utility for
collecting HDLM error
information, acquire the
error information, and then
contact your HDLM vendor
or the company for which
you have a service
contract.
KAPL01097-
W
All the current trace files will be deleted.
Is this OK? [y/n]
Details
If you set a value that is
less than the current value
of the trace file size or
number of trace files, all
the current trace files will
be deleted. To continue the
operation, enter y. To
cancel the operation, enter
n.
Action
If you want to execute the
operation of the HDLM
command, enter y. If you
want to terminate
processing, enter n.
KAPL01100-
I
aa...aa Details
This message indicates the
executed command line.
aa...aa: Name of the
executed command.
Action
None.
KAPL01101-
W
The target HBA port was not found.
Operation name = aa...aa
Details
The HBA having the
HBA_ID specified in the -
hbaid parameter could not
be found.
aa...aa: : offline,
online
Action
Messages
8-23
Hitachi Dynamic Link Manager (for AIX) User Guide
