Message
ID
Message Text Explanation
Use the view operation of
the HDLM command
(dlnkmgr view -hba) to
check the target HBA port
and the HBA_ID of the
target HBA port. After that,
specify the appropriate
HBA_ID, and then retry.
KAPL01102-
I
All the paths which pass the specified
aa...aa port will be changed to the
Offline(C) status. Is this OK? [y/n]:
Details
Multiple paths will be
collectively placed
Offline(C) because the -
hbaid or -chaid
parameter was specified.
To collectively place
multiple paths Offline(C),
enter y. To not collectively
place them Offline(C),
enter n.
aa...aa:CHA, HBA
Action
If you want to execute the
offline processing for the
paths which pass the
specified target, enter y. If
you want to terminate the
processing, enter n.
KAPL01103-
I
If you are sure that there would be no
problem when all the paths which pass
the specified aa...aa port are placed in
the Offline(C) status, enter y. Otherwise,
enter n. [y/n]:
Details
This message re-asks the
user whether to place all
the paths Offline(C). To
place all the paths
Offline(C), enter y. To not
place them Offline(C),
enter n.
aa...aa:CHA, HBA
Action
If you want to execute the
offline processing for the
paths which pass the
specified target, enter y. If
you want to terminate the
processing, enter n.
KAPL01104-
I
All the paths which pass the specified
aa...aa port will be changed to the Online
status. Is this OK? [y/n]:
Details
Multiple paths will be
collectively placed Online
because the -hbaid or -
chaid parameter was
specified. To collectively
8-24
Messages
Hitachi Dynamic Link Manager (for AIX) User Guide
