Message
ID
Message Text Explanation
place multiple paths
Online, enter y. To not
collectively place them
Online, enter n.
aa...aa:CHA, HBA
Action
If you want to execute the
Online processing for the
paths which pass the
specified target, enter y. If
you want to terminate the
processing, enter n.
KAPL01112-
E
An attempt to connect to the HDLM driver
has failed. Operation name = aa...aa
Details
HDLM driver information
must be collected to
execute the given HDLM
command, but the HDLM
driver cannot be accessed.
aa...aa: Specified
operation name
Action
Perform one of the
following procedures.
When performing an
installation
See
Installing HDLM on
page 3-18, and then
complete the installation.
When performing an
remove
See
Removing HDLM on
page 3-101, and then
complete the remove.
When performing neither
of the above, or if the
same error continues to
occur even after one of the
above procedures is
performed, execute the
DLMgetras utility for
collecting HDLM error
information, and then
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM.
For details on the
DLMgetras utility, see
DLMgetras Utility for
Messages
8-25
