Message
ID
Message Text Explanation
Collecting HDLM Error
Information on page 7-5.
KAPL01114-
W
The audit log configuration file does not
exist. Restart the HDLM Manager, and
execute the "dlnkmgr view -sys -audlog"
command and check the setting.
Details
The audit log configuration
file does not exist.
Action
Restart the HDLM
Manager, and execute the
dlnkmgr view -sys -
audlog command, and
then specify the desired
setting by using the
dlnkmgr set -audlog
command or the dlnkmgr
set -audfac command as
necessary.
KAPL01115-
W
The audit log configuration file cannot be
opened. Execute the "dlnkmgr view -sys -
audlog" command and check whether a
normal result is displayed.
Details
The audit log configuration
file cannot be opened.
Action
If the dlnkmgr view -sys
-audlog command does
not display a normal
result, contact your HDLM
vendor or maintenance
company if there is a
maintenance contract for
HDLM.
KAPL01116-
W
The audit log configuration file is invalid.
Restart the HDLM Manager, and execute
the "dlnkmgr view -sys -audlog"
command and check the setting.
Details
The audit log configuration
file is invalid.
Action
Restart the HDLM
Manager, and execute the
dlnkmgr view -sys -
audlog command, and
then specify the desired
setting by using the
dlnkmgr set -audlog
command or the dlnkmgr
set -audfac command as
necessary.
KAPL01117-
W
An error occurred during processing to
read the audit log configuration file.
Details
An internal error occurred
while reading the audit log
configuration file.
Action
Contact your HDLM vendor
or maintenance company if
8-26
Messages
Hitachi Dynamic Link Manager (for AIX) User Guide
