Message
ID
Message Text Explanation
there is a maintenance
contract for HDLM.
KAPL01118-
W
An error occurred during processing to
output the audit log configuration file.
Details
An internal parameter
error when the audit-log
data was output.
Action
Contact your HDLM vendor
or maintenance company if
there is a maintenance
contract for HDLM.
KAPL01119-
W
An error occurred during processing to
output the audit log configuration file.
Details
An internal parameter
error when the audit-log
data was output.
Action
Contact your HDLM vendor
or maintenance company if
there is a maintenance
contract for HDLM.
KAPL01120-
W
A storage system model ID could not be
displayed. Details = aa...aa, bb...bb
Details
A storage system model ID
could not be displayed.
aa...aa: Storage
recognition information
bb...bb: Error code
Action
Execute the DLMgetras
utility for collecting HDLM
error information, and then
contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL01121-
W
HNTRLib2 initialization failed. Integrated
trace information cannot be collected.
Action
Execute the HDLM
command as a user who
has root permissions.
If neither of above are the
source of the problem,
execute the DLMgetras
utility for collecting HDLM
error information, and then
contact your HDLM vendor
Messages
8-27
Hitachi Dynamic Link Manager (for AIX) User Guide
